SR/ZKHC-3100C-Wuhan Zhongke Hongchuan Technology Co., Ltd

SR/ZKHC-3100C

Product Overview：The 237 Series Near-shore Security Radar features a complete detection spectrum, with range options of 1.2 km, 3 km, 5 km, and 8 km, meeting the requirements of diverse application scenarios.

With its lightweight design and compact size, the radar is easy to install and can be mounted on light poles or existing infrastructure. It is suitable for security protection of substations, detention facilities, oil and gas pipe-lines, as well as airport perimeters and railway corridors.

Application Features：

Advanced Filtering & Anti-Interference：Same-frequency asynchronous signal ﬁltering technology eﬀectively suppresses co-channel asynchronous interference.

Easy Installation：Portable, lightweight, and compact design with low installation requirements; can be mounted on light poles or existing infrastructure.

Comprehensive Detection Range Options：Flexible range selections of 1.5km / 3km / 5km / 8km are available to adapt to various operational requirements.

High Detection Accuracy：Optimized for fast-moving targets such as large UAVs and speedboats, providing high refresh rates and continuous, stable tracking.

Technical solution →

Product Parameters

Operating mode

Phased Array System (Azimuth Mechanical Scanning + Elevation Phased Scanning)
Operating frequency band

C-band
Eﬀective Detection Capability

100m~0.8km(pedestrian)、100m~1.2km(vehicle) Azimuth
Azimuth coverage

≥90°
Detection speed

≤45W(Power Consumption)；DC12V(input);AC200~240V(input)
Data rate

0.5m/s~30m/s
Data interface

≥2Hz
Power consumption

RJ45/1Port Fast Ethernet
Operating temperature

-40°C~+55°C
Weight

≤5.5kg

Common uses

: Target Acquisition

The C1200 can detect threats from both pedestrians and vehicles at a longer range than most sniper rifles, facilitating target acquisition. Before a sniper can carry out a mission, they must first 1) confirm the presence of the target, and 2) precisely determine the target's location.

: Target Acquisition

The C1200 can detect threats from both pedestrians and vehicles at a longer range than most sniper rifles, facilitating target acquisition. Before a sniper can carry out a mission, they must first 1) confirm the presence of the target, and 2) precisely determine the target's location.

: Target Acquisition

The C1200 can detect threats from both pedestrians and vehicles at a longer range than most sniper rifles, facilitating target acquisition. Before a sniper can carry out a mission, they must first 1) confirm the presence of the target, and 2) precisely determine the target's location.
